UV RADIOMETERS

Profiling Radiometers such as the UV PowerMAP II provide an extensive “picture” of the UV source(s) and how the UV is delivered to the cure surface. The irradiance (W/cm2), energy density (J/cm2), irradiance profile (Watts/cm2 as a function of time) and the temperature profile (°C as a function of time) are available when the data is transferred to thecomputer. Profiling radiometers quickly and easily identify: ·
MicroCure Miniature UV Radiometer is an extremely small profile radiometer, both in diameter and height. This small size allows it to be placed in tight areas and to work well for small container curing (cans, tubes,  bottles).  MicroCure  gathers peak irradiance (W/cm²) and energy density (J/cm²) values which are then displayed on a small stand-alone  DataReader. MicroCure is a disposable unit. After 200 readings or  approximately one year (whichever comes first), replace your MicroCure with a fresh unit.
3DCure is a unique system for measuring the energy density (J/cm²) and peak irradiance (W/cm²) accurately on large and/or multi-dimensional objects. Up to 32 sensors in any combination of UV bandwidths can be daisy-chained together and placed on every exposure surface in order to feed information back from up to 32 varied measurement points.  Data is transferred to your PC via Cure_3D® software. Information can then be exported to a spreadsheet to allow analysis
The EIT SpotCure UV Intensity Meter is an easy portable effective method of quantifying UV output. It is a self-contained, electro-optic instrument designed to measure and display the intensity emitted by a UV curing system. Degradation of UV lamps, light guides, and reflectors can cause decreases in intensity and create curing problems. The EIT SpotCure UV Intensity Meter is designed to provide the operator with instant feedback as to the performance of the spot curing system

Measuring UV Light Intensity and UV Output

UV Radiometer Uvicure Power Plus II & UV Power Puck II MicroCure Miniature UV Radiometer
Lightweight: 0.33 ounces Measures total energy density in Joules/cm2 Measures peak power density in Watts/cm2 Battery powered High sample rate: 2000 Samples per second Automatic operation High temperature resistance
Measures UV intensity up to 20W/cm2(Standard Range) or Measures UV intensity up to 200W/cm2(Extended Range) Compact size, portable Accepts multiple light guide sizes Totally self-contained, battery-powered Instant feedback
Multiple measurement points-up to 32 UV Sensors. Small, low profile Sensor with cosine response, each calibrated and serialized. Individual Sensors are single band  Available in any of four standard (UVA, UVB, UVC or UVV) bandwidths The Sensors can be combined in any combination of bandwidths Sensors are easily attached on either a permanent or a temporary basis. Flexible connector allows Sensors to be placed without maze of cables. LED on each Sensor can be toggled via software to identify its location
UV Radiometer SpotCure Intensity Meter self-contained, electro-optic instrument designed to measure and display the intensity emitted by a UV curing system 3DCure UV Radiometer for measuring energy density peak irradiance
®
UV CURING / DRYING LAMPS
UV CURING CONVEYORS
MICROWAVE UV CURING SYSTEMS
UV Profiling Radiometer PowerMAP II
The number of lamps and bulb type in each position Lamp focus/Changes to the focus Process speed and/or exposure time variations Uniformity of the UV across bulb length The performance of individual lamps in multi-lamp systems Maintenance needs before they impact product quality System changes over time with the comparison to stored files
The UviCure Plus II (single band) and Power Puck II (four band) are easy to use and   Data Mode: UV data (Joules/cm2, Watts/cm2) displayed on one screen for up to 4 bands Graph Mode: A graph illustrating the collected UV irradiance and energy is displayed for   . Reference Mode: Allows the user to store a run into the instrument memory to allow for UV                               Setup Mode: Ability to adjust modes, display units and instrument sample rate Sample Rate: User adjustable sampling rates of 25, 128 or 2048 Hz (samples per second) Dynamic Range: Standard (10 W), Mid (1 W) or Low (100mW) range instruments, display collected data in different configurations including:  each of the UV bands.  specified at time of order along with the UV band   conditions.  Graph shows the irradiance profile as a function of time (mW/cm2 on y-axis, time on x-axis). “Profiler” version of the Power Puck II/UviCure Plus II Radiometer
The “Profiler” versions of the Power Puck II/UviCure Plus II function as standard units with the added ability to transfer the irradiance profile to a computer. The transferred data can be analyzed with EIT’s PowerView II/PowerView III  Software to allow analysis, sharing, storage and comparison of readings. Profiler units offer ease of use on the production floor (display) with the display and ability to more detailed information when profiling capabilities are needed. The sample rate of the irradiance profile transferred to a computer is 128 Hz. Faster sample rates and a thermocouple are available with the EIT PowerMAP II. Batteries (AAA) are user changeable and instruments are available in 10 W/cm2, 1 W/cm2 and 100 milliWatt/cm2 ranges.
Profiler Features Unit has display & functions the same as a Standard Puck in the same housing Profile on computer displayed at fixed sample rate of 128 Hz, approximately 100 minutes of data collection time available User changeable AAA batteries
Uvicure Power Plus II & UV Power Puck II
Power Puck® II Profiler and UviCure® Plus II Profiler
Power Plus II and UV Power Puck II UV Radiometers are used in UV Spot Curing  applications of inks, UV Adhesives, soldermasks and epoxies (not for use in web press applications). They incorporate 4 separate spectral response ranges, and measure all 4 simultaneously.
UV PowerMAP II
MicroCure Miniature UV Radiometer
SpotCure UV Intensity Meter
3DCure
Microwave UV Curing/Drying System Nordson Cool Wave 306
UV Radiometer
UV RADIOMETER
UV Curing  Lamp System uv curing conveyor
Profiling Radiometers such as the UV PowerMAP II provide an extensive “picture” of the UV source(s) and how the UV is delivered to the cure surface. The irradiance (W/cm2), energy density (J/cm2), irradiance profile (Watts/cm2 as a function of time) and the temperature profile (°C as a function of time) are available when the data is transferred to the computer. Profiling radiometers quickly and easily identify:
Power Plus II and UV Power Puck II UV Radiometers are used in UV Spot Curing  applications of inks, UV Adhesives, soldermasks and epoxies (not for use in web press applications). They incorporate 4 separate spectral response ranges, and measure all 4 simultaneously. The UviCure Plus II (single band) and Power Puck II (four band) are easy to use and display collected data in different configurations including: Data Mode: UV data (Joules/cm2, Watts/cm2) displayed on one screen for up to 4 bands Graph Mode: A graph illustrating the collected UV irradiance and energy is displayed for each of the UV bands.Graph shows the irradiance profile as a function of time(mW/cm2 on y-axis, time on x-axis). Reference Mode: Allows the user to store a run into the instrument memory to allow for UV conditions.
Setup Mode: Ability to adjust modes, display units and
MicroCure Miniature UV Radiometer is an extremely small profile radiometer, both in diameter and height. This small size allows it to be placed in tight areas and to work well for small container curing (cans, tubes, bottles). MicroCure  gathers peak irradiance (W/cm²) and energy density (J/cm²) values which are then displayed on a small stand-alone  DataReader. MicroCure is a disposable unit. After 200 readings or  approximately one year (whichever comes first), replace your MicroCure with a fresh unit.
3DCure is a unique system for measuring the energy density (J/cm²) and peak irradiance (W/cm²) accurately on large and/or multi-dimensional objects. Up to 32 sensors in any combination of UV bandwidths can be daisy-chained together and placed on every exposure surface in order to feed information back from up to 32 varied measurement points.  Data is transferred to your PC via Cure_3D® software. Information can then be exported to a spreadsheet to allow analysis
The EIT SpotCure UV Intensity Meter is an easy, portable, effective method of quantifying UV output. It is a self- contained, electro-optic instrument designed to measure and display the intensity emitted by a UV curing system. Degradation of UV lamps, light guides, and reflectors can cause decreases in intensity and create curing problems. The EIT SpotCure UV Intensity Meter is designed to provide the operator with instant feedback as to the performance of the spot curing system

Measuring UV Light Intensity and UV Output

UV Radiometers used in UV Spot Curing applications of inks, UV Adhesives and epoxies UV Profiling Radiometer PowerMAP II MicroCure Miniature UV Radiometer
Lightweight: 0.33 ounces Measures total energy density in Joules/cm2 Measures peak power density in Watts/cm2 Battery powered High sample rate: 2000 Samples per second Automatic operation High temperature resistance
Measures UV intensity up to 20W/cm2(Standard Range) or Measures UV intensity up to 200W/cm2(Extended Range) Compact size, portable Accepts multiple light guide sizes Totally self-contained, battery-powered Instant feedback
Multiple measurement points-up to 32 UV Sensors. Small, low profile Sensor with cosine response, Each calibrated and serialized. Individual Sensors are single band  Available in any of four standard (UVA, UVB, UVC or UVV) bandwidths Sensors can be combined in any combination of bandwidths Sensors attached on either a permanent or a temporary basis. Sensors to be placed without maze of cables with Connector. LED on Sensors can be toggled to identify location
UV Radiometer SpotCure Intensity Meter self-contained, electro-optic instrument designed to measure and display the intensity emitted by a UV curing system 3D Cure UV Radiometer for measuring uv energy density peak Plus II &UV Power Puck® Brochure .
  JENTON UV

Capability in UV Curing, UV Spot Curing,

UV LED Curing

Menu UV Radiometer for temperature and profiling measurement
instrument sample rate
Sample Rate: User adjustable sampling rates of 25, 128 or
Dynamic Range: Standard (10 W), Mid (1 W) or Low (100mW)
The number of lamps and bulb type in each position Lamp focus/Changes to the focus Process speed and/or exposure time variations Uniformity of the UV across bulb length The performance of individual lamps in multi-lamp systems Maintenance needs before they impact product quality System changes over time with the comparison to stored files
2048 Hz (samples per second)
range instruments,
The “Profiler” versions of the Power Puck II/UviCure Plus II function as standard units with the added ability to transfer the irradiance profile to a computer. The transferred data can be analyzed with EIT’s PowerView II/PowerView III  Software to allow analysis, sharing, storage and comparison of readings. Profiler units offer ease of use on the production floor (display) with the display and ability to more detailed information when profiling capabilities are needed. The sample rate of the irradiance profile transferred to a computer is 128 Hz. Faster sample rates and a thermocouple are available with the EIT PowerMAP II. Batteries (AAA) are user changeable and instruments are available in 10 W/cm2, 1 W/cm2 and 100 milliWatt/cm2 ranges.
UV Radiometer Power Puck® II Profiler and UviCure® Plus II Profiler UV Radiometer Power Puck® II Profiler and UviCure® Plus II Profiler
Profiler Features Unit has display & functions the same as a Standard Puck in the same housing Profile on computer displayed at fixed sample rate of 128 Hz, approximately 100 minutes of data collection time available User changeable AAA batteries
Plus II &UV Power Puck® Brochure
